2D Lidar
Mini Navi
Mini Navi
Range
Detection
Detection Angle
Angular Resolution
.png)
.png)
.png)
| Model | MINI NAVI |
| Performance Parameters | |
| Detection Distance | 0.05 m–10 m (reflectivity 10%); 0.05 m–30 m (reflectivity 90%) |
| Measurement Method | Pulse Ranging Technology (PRT) |
| Detection Angle | 320°(2D) |
| Scan Frequency | 432 K |
| Point Cloud Output Resolution | 0.025°/0.05°/0.1°/0.25°/0.5° (determined by scanning frequency, scanning motor speed, and single point sampling frequency) |
| Scanning Motor Speed | 15Hz, 30Hz (Customizable) |
| Absolute Accuracy | ±20 mm |
| Measurement Noise | ±20 mm |
| Detect Output Delay | 0-500 ms Configurable |
| Detect Maintain Delay | 0-500 ms Configurable |
| Essential Parameters | |
| Wavelength | 905 nm |
| Pulse Width | 5 ns |
| Communication | I/O, Ethernet |
| Status Indicators | 4 LED (green, yellow, orange, red) |
| Material | Aluminum Alloy, PMMA |
| IP Ratings | IP65 |
| Electrical Parameters | |
| Working Voltage | DC 10V-30V |
| Working Current | <145 mA@DC 24V |
| Rated Power | <3 W |
| Environmental Parameters | |
| Object Reflectivity | 2–1000% |
| Ambient Light | <80000 Lux (resistant to sunlight) |
| Usage Environment | -10 ℃–50 ℃ (indoor use), <80% RH (no frost, no condensation) |
