Lithium-Ion Battery
AB-BT-Customized-LT
AB-BT-Customized-LT
Cycle Life
Efficiency
Temp Range
Customization
Type | AB-BT-LFP-48V-9AH | AB-BT-LFP-48V-12AH | AB-BT-LFP-48V-20AH | AB-BT-LFP-48V-30AH | AB-BT-LFP-48V-30AH-Split | AB-BT-LFP-48V-30AH | AB-BT-LFP-48V-40AH |
Nominal Voltage | 48V | ||||||
Operating Temperature | 0℃ ~55℃ | ||||||
Operating Temperature | -20℃ ~60℃ | ||||||
Communication | RS485-ASCII/MODBUS | ||||||
Cell material | Lithium Iron Phosphate | ||||||
Cycle Life | >2000 cycles | ||||||
Full Charging(FC) Voltage | 54V | 57.6V | 54V | 54V | 54V | 54V | 54V |
Nominal Capacity | 9AH | 12AH | 20AH | 30AH | 30AH | 30AH | 40AH |
Max Charging Current | 10A | 24A | 20A | 30A | 30A | 30A | 40A |
Discharge cut-off voltage (FD) | 37.5V | 40V | 37.5V | 37.5V | 37.5V | 37.5V | 37.5V |
Maximum Discharge Current | 10A | 24A | 40A | 30A | 30A | 30A | 40A |
Dimensions | 200×150×80 mm | 190×148×140 mm | 295×99.5 ×220 mm | 255×170×180 mm | 200×155×130 mm | 300×235×135 mm | 310×250×137 mm |
Weight | 3 kg | 8 kg | 9 kg | 12.5 kg | 13kg | 13kg | 15kg |
Type | AB-BT-LFP-48V-54AH | AB-BT-LFP-48V-72AH | AB-BT-LFP-48V-100AH | AB-BT-LFP-48V-173AH | AB-BT-LFP-48V-300AH | AB-BT-LFP-48V-412AH | |
Nominal Voltage | 48V | ||||||
Operating Temperature | 0℃ ~55℃ | ||||||
Operating Temperature | -20℃ ~60℃ | ||||||
Communication | RS485-ASCII/MODBUS | ||||||
Cell material | Lithium Iron Phosphate | ||||||
Cycle Life | >2000 cycles | ||||||
Full Charging(FC) Voltage | 54V | 57.6V | 54V | 57.6V | 54V | ||
Nominal Capacity | 54AH | 72AH | 100AH | 173AH | 300AH | ||
Max Charging Current | 50A | 50A | 100A | 100A | 200A | ||
Discharge cut-off voltage (FD) | 37.5V | 44.8V | 37.5V | 40V | 37.5V | ||
Maximum Discharge Current | 50A | 50A | 100A | 100A | 200A | ||
Dimensions | 400×260×145 mm | 430×235×230 mm | 380×33×220 mm | 680×300×240 mm | 900×360×260 mm | ||
Weight | 21.5 kg | 32.5 kg | 40kg | 65kg | 105kg | ||
Type | AB-BT-LFP-24V-24AH | AB-BT-LFP-24V-30AH | AB-BT-LFP-24V-50AH | AB-BT-LFP-24V-60AH | AB-BT-LFP-24V-100AH | AB-BT-LFP-24V-210AH |
Nominal Voltage | 24V | |||||
Full Charging(FC) Voltage | 28.8V | |||||
Operating Temperature | 0℃ ~55℃ | |||||
Operating Temperature | -20℃ ~60℃ | |||||
Communication | RS485-ASCII/MODBUS | |||||
Cell material | Lithium Iron Phosphate | |||||
Cycle Life | 2000 cycles | |||||
Nominal Capacity | 21AH | 30AH | 50AH | 60AH | 100AH | 210AH |
Max Charging Current | 21A | 30A | 50A | 60A | 100A | 210A |
Discharge cut-off voltage (FD) | 20V | 22.4V | 22.4V | 22.4V | 20V | 20V |
Maximum Discharge Current | 21A | 30A | 50A | 50A | 100A | 200A |
Dimensions | 230×168×85 mm | 290×200×85 mm | 323×243×123 mm | 321×225×176 mm | 365×240×215 mm | 510×190×370 mm |
Weight | 7kg | 8 kg | 11.5 kg | 13.5 kg | 21kg | 45kg |
Type | AB-BT-LTO-24V-10AH-LT | AB-BT-LTO-24V-60AH-LT | AB-BT-LTO-48V-10AH-LT |
Operating Temperature | -30℃ ~55℃ | ||
Operating Temperature | -30℃ ~60℃ | ||
Communication | RS485-ASCII/MODBUS | ||
Cell material | Lithium Iron Phosphate(LFP) | ||
Cycle Life | 2000 cycles | ||
Nominal Voltage | 24V | 24V | |
Full Charging(FC) Voltage | 28V | 28.8V | |
Nominal Capacity | 10AH | 60AH | |
Max Charging Current | 40A | 50A | |
Discharge cut-off voltage (FD) | 17V | 16V | |
Maximum Discharge Current | 10A | 50A | |
Dimensions | 225×100×170 mm | 330×320×125 mm | |
Weight | 4kg | 18kg | |
Discover the future of AGV technology with ATOMBOTIX
