2D Lidar
Mini Navi Pro
Mini Navi Pro
Range
Detection
Detection Angle
Angular Resolution
.png)
.png)
.png)
.png)
.png)
| Model | MINI NAVI PRO |
| Performance Parameters | |
| Detection Distance | 0.05 m–10 m (reflectivity 2%) 0.05 m–50 m (reflectivity 90%) |
| Detection Angle | 360°(2D) |
| Scan Frequency | 540 Hz |
| Angular Resolution | 0.025°/0.05°/0.1°/0.25°/0.5° (determined by scanning frequency, scanning motor speed, and single point sampling frequency) |
| Scanning Motor Speed | 12.5 Hz: 750 r/min (0.025°, 0.05°, 0.1°, 0.25°, 0.5 angle resolution) 25.0 Hz: 1500 r/min (angular resolution of 0.05°, 0.1°, 0.25°, 0.5°) 50.0 Hz: 3000 r/min (0.1°, 0.2°, 0.5° angular resolution) |
| Single Point Sampling Frequency | 1-50 Hz (adjustable) |
| Recognizable Object Shape | Almost any shape |
| Measurement Resolution | 1 mm |
| Absolute Accuracy | ±20 mm |
| Measurement Noise | ±5 mm |
| Repeatability | ±10 mm |
| Essential Parameters | |
| Communication | I/O, CAN, Ethernet |
| Light Source Wavelength | 905 nm |
| Pulse Width | 5 ns |
| Switching Output | 4× NPN |
| Number of Regional Protections | 3 |
| Number of Obstacle Avoidance Channels | 16 |
| Indicator (display) Light | Green (power) Red (fault status) Yellow, Orange, Red (Output Status) |
| Material | Aluminum Alloy, PMMA |
| IP Ratings | IP65 |
| Electrical Parameters | |
| Working Voltage | DC 10–30V |
| Rated Power | <3.4 W |
| Environmental Parameters | |
| Object Reflectivity | 2 – 1000% |
| Ambient Light | <80000 Lux (resistant to sunlight) |
| Usage Environment | -10 ℃–50 ℃ (indoor use), <80% RH (no frost, no condensation) |
