Basic parameter

Navigation Method

Qr code /VSLAM/LSLAM

Drive Form

Two - wheel differential speed

Length*width*height

1150 mm×820 mm×250 mm

Maximum Load

1000 Kg

Chassis Ground Clearance

25 mm

Maximum Lifting Stroke

60 mm

Performance parameter

Navigation Position Accuracy

±10mm

Navigation Angle Accuracy

±1 °

Operating Speed(Full/empty load)

1.5 / 2 m/s

Battery parameter

Battery Capacity

48 V/40 AH Lithium iron phosphate

Rated operating time

≥8 H

Charging time (10-80%)

< 1.5 h

Charging Mode

Manual / Auto

Battery Cycle Times

Cycle 1500, capacity > 80%

Security

Number of lidars

1/2 (Optional)

Emergency Button

Support

Speaker

Support

Atmosphere Lamp

Optional

Anti - Collision Strips

Optional

Function

Basic Function

Optional

Wi-Fi Roaming Function

Optional

Automatic Charging Function

Optional

Cargo Rack Recognition Function

Optional

QR Code Precision Positioning Function

Customizable
